Description
LED emergency exit sign, complete with Arrow Up legend. Typically installed above doorways, fitting has the options for maintained or non-maintained use. Minimum 3 hour illumination during loss of power, ensuring illuminated exit routes during evacuations.
KEY FEATURES
- Ceiling mounting
- 3 hour emergency
- Maintained or non-maintained use (cannot be wired for switched-maintained use)
- Supplied as standard with Arrow Up legend
- LiFePO4 battery
- Ranges of legends available (sold separately)
- Downloads
Specifications
| SKU | EMLRECL |
|---|---|
| Brand | Knightsbridge |
| IP Rating | IP20 |
| Weight (KG) | 0.86 |
| Length | 335 |
| Height | 210 |
| Width | 76 |
| Projection | 170 |
| Recessed Depth | 40 |
| Minimum Void | 50 |
| Material | Polycarbonate |
| Finish | White |
| Testing Class | II |
| Voltage (v) | 230 |
| Emergency | Maintained / Non-maintained / Switched |
| Bulb Included | Yes |
| Dimmable | No |
| Wattage (W) | 4 |
| Colour Temperature (K) | 6000 |
| Light Colour | Daylight |
| Lumens (lm) | 15 |
| Lumens (Em. Mode) | 10 |
| Efficacy (lm/w) | 7 |
| CRI | >85 |
| Warranty (Years) | 3 |
| Warranty Information | Including battery) |
| Classification | Lighting |
| Comodity Code | 9405612090 |
| Range | Emergency Lighting |
