Description
LED double-sided suspended emergency exit sign with adjustment drop. Complete with Arrow Up legend. Typically installed above doorways, fitting can be maintained or non-maintained use. Operating a minimal 3 hour illumination during loss of power, ensuring illuminated exit routes during evacuations.
- Height/drop adjustable (maximum drop including legend 800mm)
- 3 hour emergency
- Maintained or non-maintained use (cannot be wired for switched-maintained use)
- Supplied as standard with Arrow Up legend
- LiFePO4 battery
- Ranges of legends available (sold separately)
Download
Specifications
| SKU | EMLSUSL |
|---|---|
| Brand | Knightsbridge |
| IP Rating | 20 |
| Weight (KG) | 0.87 |
| Length | 300 |
| Height | 220 |
| Width | 45 |
| Material | Polycarbonate |
| Finish | White |
| Testing Class | II |
| Voltage (v) | 230 |
| Emergency | Maintained / Non-maintained (not Switched) |
| Bulb Included | Yes |
| Dimmable | No |
| Wattage (W) | 2 |
| Colour Temperature (K) | 6000 |
| Light Colour | Daylight |
| Lumens (lm) | 15 |
| Lumens (Em. Mode) | 8 |
| Efficacy (lm/w) | 7 |
| Warranty (Years) | 3 |
| Warranty Information | (Inc battery) |
| Classification | Lighting |
| Comodity Code | 9405612090 |
| Range | Emergency Lighting |
